TOPSUN 12v 5000lbs car utv controller winch electric par 4x4
Related parameters
Share
- Warranty:1 year
- Customized support:OEM, ODM
- Place of Origin:Zhejiang, China
- Model Number:KEWC5000
- Power Source:Electric
- Application:ATV/UTV
- Voltage:12V
- Product Name:Electric Winch
- Rated Line Pull:5000LBS (2250kgs) single line
- DC:12V/24V
- Gear train:Differential Planetary
- Capacity:5000LBS
- Control:Remote, option
- Gear train ratio:235:1
- Braking Action:Automatic In-The-Drum
- Cable:6.4mmx20m
- Weight:33kg/pc
- Certification:CE
Rated Line Pull | 5000LBS (2250kgs) single line |
Motor | 1.9kw/2.6hp, permanent magnet |
Control | Remote switch, 9.8ft(3.0m)lead |
Gear train | 3 Stage Planetary |
Gear train ratio | 235:1 |
Braking Action | Automatic In-The-Drum |
Drum Size | 2.5"(64)mm×(5.3)133.5mm |
Cable | 6.4mmX20m |
Overall Dimensions | 16.3"x6.3"x8.5"(415mm×160mm×217mm) |
Mounting Bolt Pattern | 165mm×114mm Φ11 |
Weight | N.W.31kg G.W.33Kg |
Packing Size | 610×350×270mm |
